6FT USB RS232 to TTL 5V 2.54mm Dupont Header 4 Pin UART Serial Cable

6FT USB RS232 to TTL 5V 2.54mm Dupont Header 4 Pin UART Serial Cable

98.00
38.00
Length：
Color：
OEM/ODM：
Conductor：
Jacket Material：
Supply of goods：
Applied：


6FT USB RS232 to TTL 5V 2.54mm Dupont Header 4 Pin UART Serial Cable FT232R Chip for Windows,Linux and Mac OS

BrandACE-Clouds
Connector TypeUSB Type A, 6 pin header
Cable TypeUSB
Compatible DevicesLaptop, Personal Computer, Router, Modem, GPS Navigation System synthesizers, machine tool numerical controls, printers and video display terminals, Personal Computer, Router, PLD, GPS Navigation System
Special FeatureFT232 Chip


About this item

  • 6FT USB to TTL 5v 4 Pin Serial FT232 Cable Connect directly to a microcontroller UART or I/O pins.

  • The FT232RL has a low 15mA operating supply current and a very low USB suspend current of approximately 70μA. (Note that during suspend mode, the current drawn by application should not exceed 2.5mA to remain USB compliant)

  • The TTL cables are capable of operating over an extended temperature range of -40º to +85º C thus allowing them to be used in automotive or industrial applications.
